Lensagon TC5M-18-110
High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 1.8x, WD 110mm, F# 11, NA 0.081, DOF 95um, Opt.Dist. 0.03
Product Description
The Object Side Telecentric Lens TC5M-18-110 is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.
| Magnification | 1.80 x |
|---|---|
| Working Distance (WD) | 110.00 mm |
| Depth of Field (DOF) | 95.00 μm @ 20.00 μm |
| Resolution (Object Side) | 4.14 μm |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5.00 MP |
| Working F-Number | 11.00 |
| Numerical Aperture (NA) | 0.081 |
| Field of View (FOV) | 4.88mm x 3.66mm @ 2/3 |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
