Product Description
The S-Mount lens Lensagon B12M5020S117 is suitable for current sensors up to 12.00 megapixel with an image format of 1/1.7 inch. It is characterized by a particularly high light intensity.
| Mount | S-Mount |
|---|---|
| Sensor | 1/1.7 inch |
| Focal Length | 5.00 mm |
| Aperture (f#) | 2.00 |
| MOD | 0.30 m |
| Back Focal Length | 6.39 |
| Angle of View (D) | 121.40° / H: 90.00° / V: 65.00° |
| Megapixel (max.) | 12.00 MP |
| IR Correction | Yes |
| Optical Distortion | -43.70 % |
| Weight | 12.00 g |
| Iris | fixed |
| Chief ray angle | 12.72 ° |
| Typ | Standard |
