Product Description
The S-Mount lens Lensagon B5M6532S123ND is suitable for common sensors up to 5 megapixel with an image format of 1/2.5 inch.
| Mount | S-Mount |
|---|---|
| Sensor | 1/2.5 inch |
| Focal Length | 6.00 mm |
| Aperture (f#) | 3.20 |
| MOD | 0.30 m |
| Back Focal Length | 7.55 |
| Angle of View (D) | 62.00° |
| Megapixel (max.) | 5.00 MP |
| IR Correction | No |
| IR Cut Filter | No |
| Optical Distortion | 0.80 % |
| Weight | 3.05 g |
| Iris | fixed |
| Focus | fixed |
| Chief ray angle | 13.50 ° |
| Typ | Standard |
