Lensagon TC4M-10-110C
Standard Object Side Telecentric Lens for 1 inch sensor, Magnification: 1x, WD 110mm, F# 8, NA 0.062, DOF 352um, Opt.Dist. 0.03, Coaxial Version
Product Description
The Object Side Telecentric Lens TC4M-10-110C is suitable for sensors up to 4 megapixel and with an image format of 1 inch.
| Magnification | 1.00 x |
|---|---|
| Working Distance (WD) | 110.00 mm |
| Depth of Field (DOF) | 352.00 μm @ 22.00 μm |
| Resolution (Object Side) | 5.40 μm |
| Image Format (max.) | 1 inch |
| Megapixel (max.) | 4.00 MP |
| Working F-Number | 8.00 |
| Numerical Aperture (NA) | 0.062 |
| Field of View (FOV) | 11.26mm x 11.26mm |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
