Lensagon TC4MHR-026-130I
High Res Object Side Telecentric Lens for 1 inch sensor, Magnification: 0.26x, WD 130mm, F# 5.5, NA 0.0234, DOF 3600um, Opt.Dist. 0.03
Product Description
The Object Side Telecentric Lens TC4MHR-026-130I is suitable for sensors up to 4 megapixel and with an image format of 1 inch.
| Magnification | 0.26 x |
|---|---|
| Working Distance (WD) | 130.00 mm |
| Depth of Field (DOF) | 3.6 mm @ 22.00 μm |
| Resolution (Object Side) | 14.30 μm |
| Image Format (max.) | 1 inch |
| Megapixel (max.) | 4.00 MP |
| Working F-Number | 5.50 |
| Numerical Aperture (NA) | 0.0234 |
| Field of View (FOV) | 43.3mm x 43.3mm |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
