Lensagon TC4MHR-30-40C
High Res Object Side Telecentric Lens for 1 inch sensor, Magnification: 3x, WD 40mm, F# 10.7, NA 0.14, DOF 52um, Opt.Dist. 0.03, Coaxial Version
Product Description
The Object Side Telecentric Lens TC4MHR-30-40C is suitable for sensors up to 4 megapixel and with an image format of 1 inch.
| Magnification | 3.00 x |
|---|---|
| Working Distance (WD) | 40.00 mm |
| Depth of Field (DOF) | 52.00 μm @ 22.00 μm |
| Resolution (Object Side) | 2.40 μm |
| Image Format (max.) | 1 inch |
| Megapixel (max.) | 4.00 MP |
| Working F-Number | 10.70 |
| Numerical Aperture (NA) | 0.14 |
| Field of View (FOV) | 3.75mm x 3.75mm |
| Telecentric Type | Object Side |
| Telecentricity | 0.04 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
