Lensagon TC5M-07-110I
High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.7x, WD 110mm, F# 5.38, NA 0.0651, DOF 439um, Opt.Dist. 0.012
Product Description
The Object Side Telecentric Lens TC5M-07-110I is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.
| Magnification | 0.70 x |
|---|---|
| Working Distance (WD) | 110.00 mm |
| Depth of Field (DOF) | 439.00 μm @ 40.00 μm |
| Resolution (Object Side) | 5.15 μm |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5.00 MP |
| Working F-Number | 5.38 |
| Numerical Aperture (NA) | 0.0651 |
| Field of View (FOV) | 12.1mm x 10.1mm @ 2/3 |
| Telecentric Type | Object Side |
| Telecentricity | 0.02 ° |
| Optical Distortion (max.) | 0.012 % |
| Mount | C-Mount * |
* Other mounts are available on request.
