Lensagon TC5M-20-65I
Super High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 2x, WD 65mm, F# 8.3, NA 0.12, DOF 83um, Opt.Dist. 0.02
Product Description
The Object Side Telecentric Lens TC5M-20-65I is suitable for sensors up to 5 megapixel and with an image format of 2/3 inch.
| Magnification | 2.00 x |
|---|---|
| Working Distance (WD) | 65.00 mm |
| Depth of Field (DOF) | 83.00 μm @ 40.00 μm |
| Resolution (Object Side) | 2.80 μm |
| Image Format (max.) | 2/3 inch |
| Megapixel (max.) | 5.00 MP |
| Working F-Number | 8.30 |
| Numerical Aperture (NA) | 0.12 |
| Field of View (FOV) | 4.2mm x 3.6mm @ 2/3 |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.02 % |
| Mount | C-Mount * |
* Other mounts are available on request.
