Lensagon TCHR-08-65C
High Res Object Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.8x, WD 65mm, F# 8, NA 0.05, DOF 1000um, Opt.Dist. 0.134, Coaxial Version
Product Description
The Object Side Telecentric Lens TCHR-08-65C is suitable for sensors with an image format of 2/3 inch.
| Magnification | 0.80 x |
|---|---|
| Working Distance (WD) | 65.00 mm |
| Depth of Field (DOF) | 1 mm @ 40.00 μm |
| Resolution (Object Side) | 6.70 μm |
| Image Format (max.) | 2/3 inch |
| Working F-Number | 8.00 |
| Numerical Aperture (NA) | 0.05 |
| Field of View (FOV) | 11mm x 8mm @ 2/3″ |
| Telecentric Type | Object Side |
| Telecentricity | 0.02 ° |
| Optical Distortion (max.) | 0.134 % |
| Mount | C-Mount * |
* Other mounts are available on request.
