Lensagon TCST-10-113
Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 1x, WD 113mm, F# 20.8, NA 0.024, DOF 1660um, Opt.Dist. 0.023
Product Description
The Object Side Telecentric Lens TCST-10-113 is suitable for sensors with an image format of 1/2 inch.
| Magnification | 1.00 x |
|---|---|
| Working Distance (WD) | 113.00 mm |
| Depth of Field (DOF) | 1.66 mm @ 40.00 μm |
| Resolution (Object Side) | 14.00 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 20.80 |
| Numerical Aperture (NA) | 0.024 |
| Field of View (FOV) | 6.4mm x 4.8mm @ 1/2 |
| Telecentric Type | Object Side |
| Optical Distortion (max.) | 0.023 % |
| Mount | C-Mount * |
* Other mounts are available on request.
