Lensagon TCST-12-110-S13
Standard Object Side Telecentric Lens for 1/3 inch sensor, Magnification: 1x, WD 110mm, F# 18, NA 0.033, DOF 1000um, Opt.Dist. 0.03
Product Description
The Object Side Telecentric Lens TCST-12-110-S13 is suitable for sensors with an image format of 1/3 inch.
| Magnification | 1.00 x |
|---|---|
| Working Distance (WD) | 110.00 mm |
| Depth of Field (DOF) | 1 mm @ 40.00 μm |
| Resolution (Object Side) | 10.16 μm |
| Image Format (max.) | 1/3 inch |
| Working F-Number | 18.00 |
| Numerical Aperture (NA) | 0.033 |
| Field of View (FOV) | 4.0mm x 3.0mm @ 1/3″ |
| Telecentric Type | Object Side |
| Telecentricity | 0.03 ° |
| Optical Distortion (max.) | 0.03 % |
| Mount | C-Mount * |
* Other mounts are available on request.
