Lensagon TCST-30-110
Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 3x, WD 110mm, F# 27.3, NA 0.055, DOF 243um, Opt.Dist. 0.14
Product Description
The Object Side Telecentric Lens TCST-30-110 is suitable for sensors with an image format of 1/2 inch.
| Magnification | 3.00 x |
|---|---|
| Working Distance (WD) | 110.00 mm |
| Depth of Field (DOF) | 243.00 μm @ 40.00 μm |
| Resolution (Object Side) | 6.10 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 27.30 |
| Numerical Aperture (NA) | 0.055 |
| Field of View (FOV) | 2.13mm x 1.6mm @ 1/2 |
| Telecentric Type | Object Side |
| Telecentricity | 0.01 ° |
| Optical Distortion (max.) | 0.14 % |
| Mount | C-Mount * |
* Other mounts are available on request.
