Lensagon TCST-80-110
Standard Object Side Telecentric Lens for 1/2 inch sensor, Magnification: 8x, WD 110mm, F# 66.7, NA 0.06, DOF 85um, Opt.Dist. 0.25
Product Description
The Object Side Telecentric Lens TCST-80-110 is suitable for sensors with an image format of 1/2 inch.
| Magnification | 8.00 x |
|---|---|
| Working Distance (WD) | 110.00 mm |
| Depth of Field (DOF) | 85.00 μm @ 40.00 μm |
| Resolution (Object Side) | 5.60 μm |
| Image Format (max.) | 1/2 inch |
| Working F-Number | 66.70 |
| Numerical Aperture (NA) | 0.06 |
| Field of View (FOV) | 0.8mm x 0.6mm @ 1/2 |
| Telecentric Type | Object Side |
| Telecentricity | 0.015 ° |
| Optical Distortion (max.) | 0.25 % |
| Mount | C-Mount * |
* Other mounts are available on request.
