Lensagon TDC-0061-398
Standard Double Side Telecentric Lens for 2/3 inch sensor, Magnification: 0.061x, WD 398mm, F# 7, NA 0.0043, DOF 150000um, Opt.Dist. 0.05
Product Description
The Double Side Telecentric Lens TDC-0061-398 is suitable for sensors with an image format of 2/3 inch.
| Magnification | 0.061 x |
|---|---|
| Working Distance (WD) | 398.00 mm |
| Depth of Field (DOF) | 150 mm @ 40.00 μm |
| Resolution (Object Side) | 78.00 μm |
| Image Format (max.) | 2/3 inch |
| Working F-Number | 7.00 |
| Numerical Aperture (NA) | 0.0043 |
| Field of View (FOV) | 144.26mm x 108.19mm |
| Telecentric Type | Double Side |
| Telecentricity | 0.05 ° |
| Optical Distortion (max.) | 0.05 % |
| Mount | C-Mount * |
* Other mounts are available on request.
